PIPELINE

• Single-issue pipeline, example of ARM7 and ARM9
•  Example: studying how instructions are propagating through the pipeline of ARM7 and ARM9 clock per clock
•  Superscalar operation, decode and dispatch unit, example of ARM11
• Example : studying how instructions are propagating through the pipeline of ARM11 clock per clock
• Out-of-order execution
• Register renaming, scoreboarding, implementation of Tomasulo algorithm
• Reservation stations used when register interlock is detected
• Completion queue, in-order completion
• Different types of synchronization
• Example : studying how instructions are propagating through the pipeline of 750 PowerPCs
• Issue queues used to decouple the execute units from the dispatcher
• Example : studying how instructions are propagating through the pipeline of e600 PowerPC
• Hyperthreading, sharing some resources between logical cores
• Example : studying how instructions are propagating through the pipeline of Pentium IV
• Branch penalties
• Branch folding
• Mechanisms used to improve the performance of unconditional branches : Branch Target Buffer
•  Mechanisms used to improve the performance of conditional branches : static prediction vs. dynamic prediction
• Locking entries in BTB
• Taking into account instruction cache line alignment
•  Example : studying how the ARM11 core processes branches
• Example : studying how the e600 core processes branches
• Example : studying how the G5 PPC core processes branches

• Link stack : accelerating function return sequence
• Purposes : assigning attributes to memory ranges, assigning access rights to memory ranges, managing a virtual space and protecting pages
• Clarifying how the virtual address is translated into a physical address
• The Fast Context Switching Extension mechanism
•  Example : studying the ARM926 MMU
• Example : studying the new features of ARM11 MMU
• Example : studying the PowerPC MMU
• TLB organization
• Unified TLB and separate micro-TLBs
• Software TLB reload vs. hardware TLB reload
• TLB synchronization instruction when several cores are sharing the same page descriptor table

CACHES

• Cache organizations : direct-mapped, fully associative, N-way set associative Replacement algorithms, MEI vs. MESI state machines
• Write policies : write-through vs. copy-back Cache locking
• Basic cache operations : clean, flush, invalidate
• Software coherency to share data between core and external masters
• Example : studying the level 1 caches of ARM11 and the related CP15 instructions
• Example : studying the level 1 caches of e600
• Level 2 cache, understanding the data and instruction flow between external memory, level 2 cache and level 1 caches
• Example : studying the L220 IP from ARM
• Hardware coherency : the snooper
• Basic snoop requests : CLEAN, FLUSH, KILL
• Cache-to-cache data transfers Example : studying how two e600s share cache enabled data

MEMORY SUBSYSTEM

• Understanding Hit-Under-Miss and Miss- Under-Miss
•  Decoupling the core internal operation from the bus interface
• Write queues
• Load Miss queue
• Store Miss merging
• Store Miss gathering Memory barrier instructions
• Example : ARM DSB and DMB instructions

EXCEPTIONS MECHANISM

• Basic ARM exception handling
• Relationship between modes and register banks
•  Interrupts nesting, requirement of system mode
• Primecell VICs
• Reducing interrupt latency through automatic vector generation
• VIC basic signal timing
• Connectivity : daisy-chained
• VIC Interrupt priority and masking

MULTI-CORE SYSTEMS
